Description
Overview
The Böning AHD 1110 G is a 10-inch display with a glass front and touchscreen for vessel visualisation. It presents information from the connected visualisation source without requiring a separate front operating surface.
Display and visibility
Automatic dimming adapts the screen to changing ambient light and reduces glare at night. Display brightness is up to 1300 cd/m². The display arrangement is intended to maintain readable vessel information in bright bridge conditions. Wide viewing angles and colour reproduction support viewing away from the centreline. Capacitive touch operation avoids the visible sensor-thread pattern described for other touch technologies.
Marine installation
Automotive-grade components support the wider operating-temperature range described for this model series. The unit is intended for a 24 V DC vessel supply. Its all-in-one construction reduces installation space and effort, with integration into existing systems supported by the intended configuration.
Key features
- Front access to video-source selection.
- Remote operation through AHD-DRM T and AHD-DRM R or a connected PC, including a bridge-chair operating position.
Brightness specification
Maximum brightness: up to 1300 cd/m². Normal brightness stated in the technical data: 1000 cd/m².
Approvals
Manufacturer-listed approvals: DNV, CRS, LR, RS.
