Description
AVENTICS R417004027, Marex Type 244 Generation 3 control head, configuration 244-G3-E2-HYB-BL. Fibre-glass reinforced polyamide housing with IP66 protection.
Generation 3 control head for a configured Marex control system.
© AVENTICS
Control Head Type 244-G3-E2-HYB-BL
Generation 3 marine control head, 244-G3-E2-HYB-BL.
Original Product
OEM Quality
Availability
Standard Lead Timeon request
Lead Time CategoryMTO
TH 36 Marine Stock0
Additional information
| Part Number | R417004027 |
|---|---|
| Model | 244-G3-E2-HYB-BL |
| Ingress protection | IP66 |
| Housing | Fibre-glass reinforced polyamide |
Downloads
| Brochure: | AVENTICS Marex OS – Marine Technology |
|---|---|
| Brochure: | Marex Ship and Valve Controls |
| Installation instructions: | Control head Type 244 Generation 3 assembly instructions |
| Datasheet: | R417004027 technical datasheet |
| STEP and other CAD formats: | Manufacturer CAD downloads |
| Manufacturer information: | Product information and latest documents |
